*Image for reference only. Subject to the physical product or technical specifications.

Open Frame (Single Output)

65W单路输出 (HF65W-SPL-5)

Product Model：HF65W-SPL-5

Rated power
(W)：50

Input Voltage
(VAC)：85~264

Input Voltage
(VDC)：120~370

Output Voltage
(VDC)：5

Output Current
(A)：10A

Channel (s)：单路

Op. Temp.
(℃)：-30°C~+70°C

Dimension
(mm)：127*76.2*42

Product Features

This series of single-output board-mount switching power supplies adopts a compact PCB structure, significantly saving internal space in equipment. It supports a wide input voltage range, making it broadly adaptable to various power supply environments.
Integrated with multiple protection circuits including overload, overvoltage, and short circuit protection, it provides a safe and stable power solution for core application scenarios such as industrial control and communication equipment.

Compact PCB Structure Low Ripple & Noise Key Components from Renowned Domestic and International Brands 3-Year Limited Warranty
Wide Voltage Input High Efficiency, High Reliability Output Overload, Overvoltage, Short-circuit Protection
Built-in EMI Filter Wide Operating Temperature Range Natural Air Cooling

Technical Parameters

产品型号

HF65W-SPL-5
产品规格

5V10A
外形尺寸 (mm)

127×76.2×42
重量

0.25kg
输入电压范围

85~264VAC (120~370VDC)
输入启动冲击电流

冷启动， 45A/230VAC
输出电压调节范围

±10%
输出过载保护

105~150%, 打嗝模式（异常条件移除后可自动恢复）
输出过压保护

115~150%, 关断模式（电源重新上电后方可恢复）
输出过温保护

--
绝缘强度

I/P -O/P: 3.0KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min
上升时间

50ms@满载时（典型值）
保持时间

20ms@满载时（典型值）
工作温度

-30℃~+70℃ (参考减额曲线图)
安全标准

符合 UL62368-1, IEC/EN62368-1, GB4943.1
电磁兼容标准

符合 EN55032, EN55035, EN61000-3-2, 3, EN61000-4-2,3,4,5,6,8,11
接线端子

2P/7.92mm, 6P/3.96mm pitch
冷却方式

自然冷却
